FMT AdBlue® diaphragm pump 12v

Description

FMT AdBlue® diaphragm pump 12v

AdBlue® Electric Diaphragm Pump – Portable and High-Efficiency Fluid Transfer Solution

The AdBlue® Electric Diaphragm Pump is a versatile and reliable pump designed for efficient fluid transfer in a wide range of applications. With a compact design and powerful 12 V DC motor, this pump is ideal for use in locations where a battery is the only power source, such as construction sites, agricultural settings, or on boats. Engineered to provide consistent performance and long service life, the AdBlue® Electric Diaphragm Pump delivers up to 30 litres per minute (7.9 gallons per minute) and is perfect for handling AdBlue®, water, and antifreeze.

Key Features and Benefits:

This high-quality diaphragm pump is designed for self-priming, ensuring reliable operation with a maximum suction height of up to 3 meters (10 feet) and a discharge pressure of up to 1.7 bar (24.6 psi). The integrated bypass system provides smooth and controlled fluid transfer, while the pump’s lightweight construction, weighing only 5.8 kg (12.7 lbs), allows for both mobile and stationary use. The compact dimensions of 315 x 185 x 130 mm (12.4 x 7.28 x 5.11 inches) make it easy to transport and install in various locations.

Technical Specifications:

• Power and Motor: The pump is powered by a 12 V DC motor with a power consumption of 18 A and an output of 220 W. The motor operates at a speed of 2800 rpm and features an insulation class of F for enhanced safety. It is equipped with a 25 A fuse and offers a duty cycle of up to 180 minutes under free discharge, with a maximum run time of 2 minutes when the dispensing valve is closed.
• Safety and Durability: With an IP66 safety rating, this pump is protected against dust and water jets, ensuring reliable performance in challenging environments. The motor and switch case are made from shock-resistant, die-cast aluminium, while the pump housing is constructed from PA 6 GF 30 for superior durability. The encapsulated motor design minimizes condensation and prevents short-circuits caused by extreme temperature fluctuations.
• Ease of Use: The pump features a freely positional pump case that can be adjusted in all 90° positions, enhancing flexibility and ease of installation. It comes with a connecting cable with battery terminal clips and a fuse holder for straightforward setup and operation.

Versatility in Applications:

The FMT AdBlue® diaphragm pump 12v is a versatile solution suitable for various fluid transfer applications. Its ability to operate both mobile and stationary makes it perfect for situations where conventional power sources are unavailable, such as remote construction sites, agricultural settings, or marine environments. The pump’s efficient design and robust materials guarantee a long service life and optimized performance in any setting.

Packaging Information:

• Dimensions: 338 x 200 x 196 mm (13.3 x 7.8 x 7.7 inches)
• Weight (including packaging): 6.4 kg (14.1 lbs)
• Packing Unit: 1

Choose the AdBlue® Electric Diaphragm Pump for a portable, efficient, and reliable fluid transfer solution. With its high-quality construction and adaptable design, this pump is built to deliver exceptional performance and longevity in any environment.

Unlike most economy AdBlue pumps on the market we offer a complete interchangeable replacement diaphragm unit should your pump require it –  FMT AdBlue pump Diaphragm replacement unit.

Additional information

Data Sheet P-25-281 DEF-ADBLUE 12V PUMP SPEC SHEET

Operating Manual P-25-281 AdBlue 12v Pump
