Piusi K33 ATEX Approved Fuel Flow Meter

Description

The Piusi K33 ATEX Flow Meter is a precision instrument designed for measuring the transfer of diesel, petrol, or kerosene. Utilizing a reliable nutating disk system, this fuel counter meter is specifically engineered for use in flammable environments, boasting ATEX certification. This ensures its suitability for safe operation in hazardous areas. The K33 ATEX flow meter has a measurement capacity of up to 999.9 litres, making it a robust and dependable choice for various fuel transfer applications.

One of the standout features of the K33 ATEX flow meter is its mechanical display, which provides a clear and accurate reading of fuel usage. This meter is manufactured in Italy by Piusi, a renowned name in the industry known for their high-quality, reliable, and cost-effective solutions. The mechanical nature of the K33 meter not only enhances its durability but also simplifies installation and calibration processes, making it an economical option for users.

The Piusi K33 diesel fuel flow meter is versatile and adaptable, thanks to its broad flow range. It is suitable for both pump and gravity-fed installations. Moreover, its face can be rotated to facilitate fuel flow in four different directions, adding to its flexibility. This adaptability is further highlighted in an instructional video that demonstrates how to change the flow direction to meet specific installation needs.

For those not requiring ATEX certification, Piusi also offers a standard K33 meter, ideal for dispensing diesel fuel or oil.

It is important to note that when using the meter with HVO (Hydrotreated Vegetable Oil), recalibration is necessary to account for its specific gravity (SG) of 0.78, compared to diesel’s SG of 0.84.

Key Features of the Piusi K33 ATEX Fuel Flow Meter:

• Mechanical fuel flow meter
• Flow rate: 20-120 litres per minute
• Rotatable to allow flow from four directions
• 1” F x F BSP inlet/outlet
• Polybutylene nutating disk system
• Accuracy of +/-1% post-calibration
• Operational temperature range: -20°C to +60°C
• Three-digit resettable and six-digit non-resettable totalizer
• ATEX certification: 2 G IIB T=85°C (T6)
• Compatible with diesel, petrol, kerosene, AVGAS, and JET A1

The Piusi K33 ATEX fuel flow meter represents a blend of safety, reliability, and practicality, making it an excellent choice for those operating in potentially explosive environments. Its ease of use, coupled with its precision and versatility, underscores its position as a leading solution in fuel measurement.

We offer a comprehensive range of ATEX rated equipment here – ATEX Refuelling Equipment
