AFV-1003 Atkinson Three-Way Filter Valve
FEATURES OF THE ATKINSON THREE-WAY FILTER VALVE:
- Connect more than one appliance to your oil line
- 3 outlet ports from your oil tank
- Blanking plugs supplied
- Service kit available
From £2.28 £2.74
- Description
- Additional information
- Technical Downloads
- Reviews (0)
Description
Atkinson 3 way Filter Valve
This has three outlets, one either side of the body (not shown in picture) thus exiting at right angles to the tank, one to the left and one to the right. These outlets can be utilised using the two standard 3/8″ x 10mm compression fittings (one supplied) or either one of these can be closed off using the 3/8″ BSP blanking plug supplied.
The latest design from Atkinson Equipment, featuring an isolation valve, 52 micron nylon filter element, 1″ BSP male tank-fitting adaptor, and a back nut to lock the filter in the correct orientation once the adaptor has been tightened. The valve utilises same filter bowl and filter element used in the Tankmaster Valve.
The outlets are 3/8″ BSP Female and this comes supplied with 1 x 3/8″ BSP Male to 10mm compression fittings and two blanking plug as standard (in case only one outlet is used).
Comes c/w a roll of PTFE tape for the tank connection
If you require extra compression fittings please select from the drop down box.
As well as the Atkinson 3 way Filter Valve we also offer the standard Filter Valve – AFV-1000 Filter Valve
In addition to the standard AFV-1000 filter valve we also manufacture our version which utilises the same filter element from the Tankmaster which widely available in most plumbing stores, it also uses the same filter bowl so spares are available unlike the AFV-1000. This filter valve can be found here – AFV-2000 Filter Valve
Additional information
| Weight | 0.5 kg |
|---|
