FMT 12V-35lpm Diesel Transfer Vane Pump

Description

FMT 12V-35lpm Diesel Vane Pump

A top quality, Swiss-made sliding-vane pump, designed for use with diesel and other products which are not aggressive to the pumps component materials. Due to their unsurpassed reliability on continuous duty operations, these can also be used as process pumps.

• Specification – Vane pump, with integral bypass
• On/Off switch
• Fuse
• Siphon protection acc. to WHG (German government regulation for environmental care), continuously active

Technical data

• Connecting cable with battery terminal clips, length (m) / (ft) 3 / 10
• Connection suction side G 1” female
• Connection discharge side G 1” female
• Hydraulic data
• Pumping media fuel oil and diesel
• Pump design vane pump, self priming
• Delivery rate under free discharge up to (l/min) / (gpm) 35 / 9.2
• Suction height up to (m) / (ft) 3 / 10
• Discharge pressure up to (bar) / (psi) 1,6 / 23.2

Motor data

• Insulation class F
• Highest permissible limit temperature (°C) / (°F) 155 / 311
• Voltage (V) 12 V DC
• Power consumption (A) 19
• Power (W) 230
• Fuse (A) 25 A plug-in fuse
• Duty cycle (min) under free discharge max. 180
• Run time (min) when dispensing valve is closed max. 2
• Torque (Nm) 0,38
• Rotation speed (rpm) 3000
• Type of construction IMB 5
• Safety class IP66

Special notes

• First class construction of electric machines and pumps
• Continuous operation – 3 hours – with open valve
• Lapped shaft on the sealing point
• Encapsulation of the electric motor, which, in case of extreme temperature fluctuations, largely prevents the formation of condensed water and of short-circuits resulting thereof
• Pump case freely positional in all 90° positions
• Switch case freely positional in all 90° positions
• Switch case made of shock resistant, die-cast zinc, coated by catachresis
• Pump case made of seawater resistant die-cast aluminium, coated by catachresis
• Motor case, completely galvanised, coated external parts
• Small tolerances provide a high suction- and pressure performance at best efficiency
• The material composition of the vane-stator (runner ring) guarantees form-stability of the vanes up to 200 °C / 392 °F
• Materials guarantee a low weight and an exceptional lifetime with optimized efficiency

Materials of parts in contact with liquid

• Seals FKM (Viton®)/NBR
• Pump housing AlSi 12 (sea water resistant)
• Rotor GG 25
• Vane POM

Pump Dimensions

Dimensions L x W x H (mm) / (inch) 270 x 120 x 120 / 10.6 x 4.7 x 4.7
Weight (kg) / (lb) 5 / 11

Packaging

• Dimensions L x W x H (mm) / (inch) 300 x 170 x 160 / 11.8 x 6.7 x 6.3
• Weight including package (kg) / (lb) 5,6 / 12.4
• Packing unit 1,0

As well as the FMT 12V-35lpm Diesel Vane Pump we also supply the complete range of FMT Pumps here – FMT Diesel Transfer Pumps
